Product Description
This 2011 Sumitomo SH350-5 excavator is now available at a competitive price point in Fujian, China. The SH350-5 represents Sumitomo's reliable hydraulic excavator platform, engineered for demanding construction and earthmoving applications. With over a decade of service, this machine offers proven field performance backed by Sumitomo's reputation for durable components and efficient hydraulic systems.
Key features of the SH350-5 series include:
- Operating weight class suitable for mid to large-scale projects
- Fuel-efficient engine design for extended operational periods
- Robust undercarriage built for varied terrain conditions
- Spacious operator cab with ergonomic controls
- Hydraulic system optimized for productivity and precision
This unit is currently stationed in Fujian and ready for inspection. Ideal for contractors seeking dependable used equipment with established maintenance history. Contact us for detailed specifications, current condition assessment, and pricing information.
| Specifications | Value |
|---|---|
| No. | 1156382 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | AH-6HK1XYSS |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
