Product Description
Discover the robust performance and reliability of the 2020 Sumitomo SH460HD-5, now available in Zhejiang, China. This heavy-duty excavator is designed for demanding construction and excavation projects, offering superior digging force and stability. Built with advanced engineering, it ensures efficient operation and minimal downtime, making it a valuable asset for any fleet.
- Model: SH460HD-5
- Year: 2020
- Location: Zhejiang, China
- Brand: Sumitomo
| Specifications | Value |
|---|---|
| No. | 1097520 |
| Tonnage (tons) | 46 |
| Working weight (kg) | 45900 |
| Bucket capacity (m³) | 1.8-2.0 |
| Boom length (mm) | 6980 |
| Rod length (mm) | 3380 |
| Country of origin | Xiamen (in Fujian Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 270/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 9.839 |
| Working form | Four-stroke, direct injection, fully electronically controlled, turbocharged diesel engine with intercooling |
| Ground specific pressure (Kpa) | 85 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | |
| Rod digging force (kN) | |
| Maximum tractive force (kN) | 341 |
| Travel speed (km/h) | 3.1/5.3 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Variable axial piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 230 |
| Total transport length (mm) | 12010 |
| Total transport width (mm) | 3350 |
| Total transport height (mm) | 3600 |
| Full cab height (mm) | 3290 |
| Counterweight ground clearance (mm) | 1330 |
| Minimum ground clearance (mm) | 540 |
| Minimum turning radius of front working device (mm) | 4990 |
| Back end turning radius (mm) | 3680 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2750 |
| Track plate width (mm) | 600/750 |
| Total track width (mm) | 3350 |
| Track ground length (mm) | 4050 |
| Maximum digging radius (mm) | 12000 |
| Maximum digging depth (mm) | 7720 |
| Maximum excavation height (mm) | 11140 |
| Maximum unloading height (mm) | 7740 |
| Maximum vertical digging depth (mm) | 6570 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
