Product Description
Discover the 2018 Volvo EC120DL, a robust and reliable excavator available for purchase in Hebei, China. This machine is verified by its original company records, ensuring transparency and trust. The EC120DL comes equipped with genuine Volvo-branded components, including the original tracks, which are a testament to its authenticity and quality. Featuring hydraulic quick couplers, this excavator offers enhanced versatility and efficiency on the job site. Known for its solid performance, this model has not undergone any major overhauls, maintaining its original integrity. Priced competitively, it presents an excellent value for businesses looking to expand their fleet without compromising on quality.
- Year: 2018
- Brand: Volvo
- Model: EC120DL
- Location: Hebei, China
- Equipped with genuine Volvo parts
- Hydraulic quick coupler included
- No major components have been replaced
| Specifications | Value |
|---|---|
| No. | 1143403 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12230 - 14170 |
| Bucket capacity (m³) | 0.2 - 0.52 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D3.8E |
| Rated power (kw/rpm) | 77.4/2200 |
| Cylinder diameter × stroke (mm) | 100*120 |
| Maximum torque (N.m) | 369.5/1500 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.77 |
| Rotation speed (rpm) | 11.2 |
| Bucket digging force (kN) | 82.2 |
| Rod digging force (kN) | 61.8 |
| Maximum tractive force (kN) | 119 |
| Travel speed (km/h) | 2.9/5.2 |
| Turning torque (Nm) | 30.2 |
| Maximum flow of main pump (l/min) | 2 x 118 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 24.5 |
| Main pump type | 2× variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 32.4/34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 1 x 22 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 865 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 * 120 * 1045 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 105 x 980 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 13.2 |
| Coolant (L) | 22.3 |
| Hydraulic System (L) | 230 |
| Total transport length (mm) | 7720 |
| Total transport width (mm) | 2490 |
| Full cab height (mm) | 2800 |
| Counterweight ground clearance (mm) | 920 |
| Minimum ground clearance (mm) | 436 |
| Back end turning radius (mm) | 2200 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 44 |
| Maximum digging radius (mm) | 8330 |
| Maximum digging depth (mm) | 5530 |
| Maximum excavation height (mm) | 8390 |
| Maximum unloading height (mm) | 6020 |
| Maximum vertical digging depth (mm) | 4960 |
| Maximum excavation radius of stop surface (mm) | 8190 |
