HOME>>Volvo>>Volvo EC120DL

2018 Volvo EC120DL

1/9
Buy Volvo EC120DL Used Excavator / 1
Buy Volvo EC120DL Used Excavator / 2
Buy Volvo EC120DL Used Excavator / 3
Buy Volvo EC120DL Used Excavator / 4
Buy Volvo EC120DL Used Excavator / 5
Buy Volvo EC120DL Used Excavator / 6
Buy Volvo EC120DL Used Excavator / 7
Buy Volvo EC120DL Used Excavator / 8
Buy Volvo EC120DL Used Excavator / 9

Product Description

2018 Volvo EC120DL crawler excavator available from Hebei, China. This 12-ton class machine features verified company service records and genuine Volvo components throughout, including branded original panels and guards. Equipped with hydraulic quick coupler for efficient attachment changes on site.

  • Year: 2018
  • Model: Volvo EC120DL
  • Location: Hebei Province, China
  • Condition: Major components unmodified, original configuration
  • Features: Hydraulic quick coupler, genuine Volvo branded parts

This unit demonstrates reliable performance characteristics typical of the EC120DL platform. All major assemblies remain in original factory condition with no major overhauls or component replacements. Competitively priced for the regional market. Suitable for contractors requiring proven mid-size excavation capacity with established OEM support networks.

SpecificationsValue
No.1143551
Tonnage (tons)12
Working weight (kg)12230 - 14170
Bucket capacity (m³)0.2 - 0.52
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD3.8E
Rated power (kw/rpm)77.4/2200
Cylinder diameter × stroke (mm)100*120
Maximum torque (N.m)369.5/1500
Number of cylinders (PCS)4
Displacement (L)3.77
Rotation speed (rpm)11.2
Bucket digging force (kN)82.2
Rod digging force (kN)61.8
Maximum tractive force (kN)119
Travel speed (km/h)2.9/5.2
Turning torque (Nm)30.2
Maximum flow of main pump (l/min)2 x 118
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)24.5
Main pump type2× variable axial piston pump
Working Hydraulic Circuit (Mpa)32.4/34.3
Pilot Oil Circuit (MPa)3.9
Pilot pump flow (L/min)1 x 22
Bucket cylinders - Number × diameter × stroke (mm)1 x 100 x 865
Bucket rod cylinders - Number × diameter × stroke (mm)1 * 120 * 1045
Boom cylinders - Number × diameter × stroke (mm)2 x 105 x 980
Fuel Tank (L)250
Hydraulic Tank (L)85
Engine Oil changes (L)13.2
Coolant (L)22.3
Hydraulic System (L)230
Total transport length (mm)7720
Total transport width (mm)2490
Full cab height (mm)2800
Counterweight ground clearance (mm)920
Minimum ground clearance (mm)436
Back end turning radius (mm)2200
Total track length (mm)3580
Track gauge (mm)1990
Track plate width (mm)500
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)44
Maximum digging radius (mm)8330
Maximum digging depth (mm)5530
Maximum excavation height (mm)8390
Maximum unloading height (mm)6020
Maximum vertical digging depth (mm)4960
Maximum excavation radius of stop surface (mm)8190
see more

Overview

No.1143551

Brand Name:

Volvo

Model Number:

EC120DL

Year:

2018

Location:

Hebei China

Pub Date
