2022 Volvo EC18D

1/9
Buy Volvo EC18D Used Excavator / 1
Buy Volvo EC18D Used Excavator / 2
Buy Volvo EC18D Used Excavator / 3
Buy Volvo EC18D Used Excavator / 4
Buy Volvo EC18D Used Excavator / 5
Buy Volvo EC18D Used Excavator / 6
Buy Volvo EC18D Used Excavator / 7
Buy Volvo EC18D Used Excavator / 8
Buy Volvo EC18D Used Excavator / 9

Product Description

This 2022 Volvo EC18D compact excavator offers proven performance for confined jobsites. Currently located in Hebei, China, this imported unit features the articulated boom and extendable undercarriage that define Volvo's compact excavator line. The machine comes equipped with standard auxiliary hydraulics, enabling attachment versatility forbreakers and specialized buckets.

  • Year: 2022
  • Model: Volvo EC18D
  • Location: Hebei, China
  • Articulated boom for increased working range
  • Extendable undercarriage for enhanced stability
  • Auxiliary hydraulic system compatible with breakers and buckets
  • Fuel-efficient operation

The EC18D delivers responsive hydraulics and maneuverability in urban construction, landscaping, and utility applications. This used unit represents an opportunity to acquire Volvo's compact excavator engineering at pre-owned value. Inspection welcomed.

SpecificationsValue
No.1145101
Tonnage (tons)1.8
Working weight (kg)1770
Bucket capacity (m³)0.01 - 0.05
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD0.9A
Rated power (kw/rpm)12/2420
Cylinder diameter × stroke (mm)72 x 73.6
Maximum torque (N.m)51
Number of cylinders (PCS)3
Displacement (L)898
Ground specific pressure (Kpa)30.5
Rotation speed (rpm)9.5
Climbing ability (%)30
Bucket digging force (kN)1510
Travel speed (km/h)3.7
Turning torque (Nm)243
Main overflow set pressure (Mpa)17
Maximum flow of main pump (l/min)34
Main pump typeGear pump
Fuel Tank (L)20
Hydraulic Tank (L)15
Engine Oil changes (L)3.7
Coolant (L)4
Hydraulic System (L)21
Total transport length (mm)3770
Total transport height (mm)2318
Minimum ground clearance (mm)159
Minimum turning radius of front working device (mm)1452
Back end turning radius (mm)1052
Onboard width (mm)993
Track plate width (mm)230
Total track width (mm)1336
Number of wheels (single side) (each)3
Maximum digging radius (mm)3856
Maximum digging depth (mm)2387
Maximum excavation height (mm)3460
Maximum unloading height (mm)2462
Maximum vertical digging depth (mm)1772
Dodging plate width × height (mm)238*230
Maximum excavation radius of stop surface (mm)3799
see more

Overview

No.1145101

Brand Name:

Volvo

Model Number:

EC18D

Year:

2022

Location:

Hebei China

Pub Date
