Product Description

This 2014 Volvo EC250D excavator represents reliable performance from one of the industry's most trusted manufacturers. Built during Volvo's mature EC-D series production, this machine combines proven hydraulic efficiency with operator-focused cabin design. Sourced from Zhejiang, China, it offers established technology suitable for general earthmoving, trenching, and site development applications.

Key attributes of the EC250D platform include:

  • 25-ton operating weight class for medium-duty applications
  • Volvo D6E engine meeting Tier 3 emissions standards
  • Advanced hydraulic system with multiple working modes
  • Spacious ROPS/FOPS certified cabin with enhanced visibility
  • Durable undercarriage designed for extended service life

This unit provides a practical solution for contractors seeking proven Volvo engineering at a competitive price point. Contact us for detailed inspection reports, operational hours, and export documentation to your destination.

SpecificationsValue
No.1170839
Tonnage (tons)25
Working weight (kg)24600 - 28000
Bucket capacity (m³)0.48 - 1.85
Country of originKorea
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD7E
Rated power (kw/rpm)138/1800
Cylinder diameter × stroke (mm)108*130
Maximum torque (N.m)870 / 1 350
Number of cylinders (PCS)6
Displacement (L)7.1
Rotation speed (rpm)11.9
Bucket digging force (kN)152
Rod digging force (kN)115
Maximum tractive force (kN)217
Travel speed (km/h)3.5/5.5
Turning torque (Nm)91.6
Maximum flow of main pump (l/min)2 x 240
Traveling Hydraulic Circuit (Mpa)36.3
Control Hydraulic Circuit (Mpa)3.9
Fuel Tank (L)470
Hydraulic Tank (L)195
Engine Oil changes (L)32
Coolant (L)41
Hydraulic System (L)400
Total transport length (mm)10260
Total transport width (mm)2990
Full cab height (mm)3020
Counterweight ground clearance (mm)1080
Minimum ground clearance (mm)470
Back end turning radius (mm)3070
Onboard width (mm)2890
Total track length (mm)4450
Track gauge (mm)2390
Track plate width (mm)600
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10260
Maximum digging depth (mm)6980
Maximum excavation height (mm)9690
Maximum unloading height (mm)6 800
see more

Overview

No.1170839

Brand Name:

Volvo

Model Number:

EC250D

Year:

2014

Location:

Zhejiang China

Pub Date:
