Product Description
Discover the reliability and performance of the 2016 Volvo EC250D excavator, available for immediate delivery from Sichuan, China. This machine has been meticulously maintained and is in excellent condition, making it a top choice for demanding construction projects. With over 150,000 hours of operational history, this excavator continues to deliver the robust performance Volvo is known for. Ideal for contractors and construction firms looking for a dependable, high-quality excavator that can handle tough jobs with ease.
- Year: 2016
- Brand: Volvo
- Model: EC250D
- Operational Hours: Over 150,000
- Location: Sichuan, China
| Specifications | Value |
|---|---|
| No. | 1057350 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24600 - 28000 |
| Bucket capacity (m³) | 0.48 - 1.85 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D7E |
| Rated power (kw/rpm) | 138/1800 |
| Cylinder diameter × stroke (mm) | 108*130 |
| Maximum torque (N.m) | 870 / 1 350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.1 |
| Rotation speed (rpm) | 11.9 |
| Bucket digging force (kN) | 152 |
| Rod digging force (kN) | 115 |
| Maximum tractive force (kN) | 217 |
| Travel speed (km/h) | 3.5/5.5 |
| Turning torque (Nm) | 91.6 |
| Maximum flow of main pump (l/min) | 2 x 240 |
| Traveling Hydraulic Circuit (Mpa) | 36.3 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Fuel Tank (L) | 470 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 10260 |
| Total transport width (mm) | 2990 |
| Full cab height (mm) | 3020 |
| Counterweight ground clearance (mm) | 1080 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3070 |
| Onboard width (mm) | 2890 |
| Total track length (mm) | 4450 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10260 |
| Maximum digging depth (mm) | 6980 |
| Maximum excavation height (mm) | 9690 |
| Maximum unloading height (mm) | 6 800 |
