Product Description
Discover the reliability and efficiency of the 2016 Volvo EC250D, a robust excavator designed for demanding industrial applications. This machine, currently located in Jiangsu, China, has proven its durability and performance in various construction environments. With an operating weight that enhances stability and control, the EC250D is equipped to handle tough digging and lifting tasks with precision. Ideal for contractors and construction companies looking for a dependable, used excavator, this model offers a balance of power, comfort, and versatility. It's ready to be your next reliable asset on any job site.
- Year: 2016
- Brand: Volvo
- Model: EC250D
- Location: Jiangsu, China
| Specifications | Value |
|---|---|
| No. | 1119858 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24600 - 28000 |
| Bucket capacity (m³) | 0.48 - 1.85 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D7E |
| Rated power (kw/rpm) | 138/1800 |
| Cylinder diameter × stroke (mm) | 108*130 |
| Maximum torque (N.m) | 870 / 1 350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.1 |
| Rotation speed (rpm) | 11.9 |
| Bucket digging force (kN) | 152 |
| Rod digging force (kN) | 115 |
| Maximum tractive force (kN) | 217 |
| Travel speed (km/h) | 3.5/5.5 |
| Turning torque (Nm) | 91.6 |
| Maximum flow of main pump (l/min) | 2 x 240 |
| Traveling Hydraulic Circuit (Mpa) | 36.3 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Fuel Tank (L) | 470 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 10260 |
| Total transport width (mm) | 2990 |
| Full cab height (mm) | 3020 |
| Counterweight ground clearance (mm) | 1080 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3070 |
| Onboard width (mm) | 2890 |
| Total track length (mm) | 4450 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10260 |
| Maximum digging depth (mm) | 6980 |
| Maximum excavation height (mm) | 9690 |
| Maximum unloading height (mm) | 6 800 |
