2016 Volvo EC300D

1/8
Buy Volvo EC300D Used Excavator / 1
Buy Volvo EC300D Used Excavator / 2
Buy Volvo EC300D Used Excavator / 3
Buy Volvo EC300D Used Excavator / 4
Buy Volvo EC300D Used Excavator / 5
Buy Volvo EC300D Used Excavator / 6
Buy Volvo EC300D Used Excavator / 7
Buy Volvo EC300D Used Excavator / 8

Product Description

This 2016 Volvo EC300D hydraulic excavator is currently located in Yunnan, China and available for immediate inspection. With approximately eight years of field operation, this 30-ton class machine represents proven Volvo reliability in the mid-size excavator segment. The EC300D is engineered for demanding earthmoving, demolition, and general construction applications where performance and fuel efficiency are essential.

Key features of the Volvo EC300D include:

  • Volvo D7E turbocharged diesel engine delivering efficient power output
  • Advanced hydraulic system for precise control and productivity
  • Spacious ROPS/FOPS certified operator cabin with ergonomic controls
  • Durable undercarriage designed for extended service life
  • Multiple working modes to optimize fuel consumption

Comprehensive photo and video documentation available. Suitable for contractors seeking dependable excavation equipment with established service history. Pricing reflects current market conditions for units of this age and specification.

SpecificationsValue
No.1163596
Tonnage (tons)30
Working weight (kg)30040
Bucket capacity (m³)1.4
Boom length (mm)6430
Rod length (mm)3710
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD7E
Rated power (kw/rpm)169/1800
Cylinder diameter × stroke (mm)108 x 130
Maximum torque (N.m)1080/1350
Number of cylinders (PCS)6
Displacement (L)7.1
Working formTurbocharged, 4-stroke, water-cooled, direct injection
Rotation speed (rpm)10.7
Climbing ability (%)35 °
Maximum tractive force (kN)247
Travel speed (km/h)3.4/5.4
Turning torque (Nm)110.9
Maximum flow of main pump (l/min)2 x 263
Traveling Hydraulic Circuit (Mpa)36.3
Rotary Hydraulic Circuit (Mpa)27.9
Working Hydraulic Circuit (Mpa)33.3/36.3
Bucket cylinders - Number × diameter × stroke (mm)1 x 140 x 1140
Bucket rod cylinders - Number × diameter × stroke (mm)1 x 150 x 1745
Boom cylinders - Number × diameter × stroke (mm)2 x 140 x 1480
Fuel Tank (L)470
Hydraulic Tank (L)195
Coolant (L)41
Hydraulic System (L)400
Total transport length (mm)10640
Total transport width (mm)3190
Total transport height (mm)3090
Full cab height (mm)3090
Counterweight ground clearance (mm)1135
Minimum ground clearance (mm)480
Onboard width (mm)890
Total track length (mm)4870
Track plate width (mm)600
Maximum digging radius (mm)10190
Maximum digging depth (mm)6850
Maximum excavation height (mm)9660
Maximum unloading height (mm)6670
Maximum vertical digging depth (mm)5730
Maximum excavation radius of stop surface (mm)9980
Maximum effective digging depth (mm)6610
see more

Overview

No.1163596

Brand Name:

Volvo

Model Number:

EC300D

Year:

2016

Location:

Yunnan China

Pub Date:
