Product Description
This 2017 Volvo L350F wheel loader offers proven performance for quarrying, mining, and heavy material handling operations. Manufactured by Volvo Construction Equipment, the L350F is recognized for its robust design and operational efficiency in demanding environments.
Key features of the Volvo L350F include:
- High-capacity wheel loader configuration suitable for large-scale operations
- Volvo's OptiShift transmission system for smooth power delivery
- Reinforced Z-bar linkage for excellent breakout force
- Spacious ROPS/FOPS certified operator cabin
- Advanced hydraulic system for responsive bucket control
Currently located in Sichuan, China, this unit represents a cost-effective solution for buyers seeking reliable used heavy equipment. The L350F's established track record in Asian markets makes it a practical choice for contractors and operators requiring dependable loading capacity.
| Specifications | Value |
|---|---|
| No. | 1171474 |
| Engine type | Volvo D16E LA E3 |
| Maximum torque (N.m) | 2550/1800 |
| Exhaust volume (L) | 16 |
| Rated power (kw/rpm) | 70 |
| Battery voltage (V) | 24 |
| Battery capacity (kWh) | 2x170 Ah |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 37810-40030 |
| Digging force (lifting force) (kN) | 356.8-504.7 |
| Machine operating weight (kg) | 49810-51030 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 365 |
| Coolant (L) | 68 |
| Engine Oil (L) | 40 |
| Wheelbase (mm) | 4300 |
| Minimum ground clearance (mm) | 550 |
| Machine length (mm) | 8240 |
| Machine width (mm) | 3630 |
| Machine height (mm) | 4180 |
| Tyre specification | 35/65 R33 875/65 R33 |
| Hydraulic pump type | |
| Flow rated speed (l/min) | 354 |
| Rated working pressure (bars) | 260 |
| Lift (s) | 8 |
| Unloading (s) | 1.9 |
| Lower empty bucket (s) | 4.7 |
| Ternary sum (s) | 14.6 |
| Gearbox brand and model | Volvo HTE 400 |
| Speed 1 gear (km/h) | 6.8/7.5 |
| Speed 2 (km/h) | 12.1/13.2 |
| Speed 3 (km/h) | 21.0/22.9 |
| Speed 4 (km/h) | 35.7/38.2 |
| Tipping load (kg) | 34290 |
| Starting motor Power (kw) | 70 |
| Service brake | |
| Parking and emergency braking |
