Product Description
Operators benefit from proven engineering in this 2016 XCMG 20K5 rough terrain crane, currently located in Lianyungang, Jiangsu Province. Designed for precision lifting in challenging ground conditions, this 20-ton capacity machine delivers responsive hydraulic controls and stable load handling across uneven surfaces. The cabin provides commanding 360-degree visibility through large reinforced glass panels, enabling operators to monitor rigging points and site obstacles with minimal blind spots.
- Hydraulic outriggers ensure level positioning on sloped or soft terrain
- Proportional joystick controls allow smooth load placement and reduced swing
- Elevated operator position improves sightlines to boom tip and load path
- Robust chassis construction maintains stability during pick-and-carry operations
- Accessible service points reduce daily inspection time
Built during XCMG's quality-focused production period, this unit combines reliable mechanical systems with practical operator ergonomics. Suitable for construction sites, industrial maintenance, and infrastructure projects requiring mobile lifting capacity with operator confidence.
| Specifications | Value |
|---|---|
| No. | 1012501 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
