Product Description
Built for demanding jobsites, this 2018 XCMG 20k5 delivers the power and precision you need to tackle digging, grading, and material handling without delay. Currently positioned in Handan, Hebei, this machine arrives ready to deploy on your next project with proven hydraulic performance and robust construction that meets real-world operational demands.
- Reliable 20-ton lifting capacity handles heavy loads with stability
- Responsive hydraulic system ensures smooth, controlled operation
- Durable XCMG engineering proven across construction and industrial applications
- Immediate availability from Handan, Hebei location
- 2018 model year provides modern functionality without excessive wear
Whether you're excavating foundations, loading trucks, or positioning structural components, this crane integrates directly into your workflow. No extended setup, no waiting—just dependable lifting power that keeps your schedule moving forward. Contact Fair Trade Machinery today to arrange inspection or discuss delivery logistics for your operation.
| Specifications | Value |
|---|---|
| No. | 1024161 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
