Product Description
Acquire proven performance without the premium price tag. This 2021 XCMG 20L5 delivers the reliability and power your operation demands at a fraction of new equipment cost. Built by one of China's most trusted heavy machinery manufacturers, this model combines advanced engineering with exceptional value retention.
Currently located in Hunan Loudi, this unit represents a strategic acquisition for contractors seeking to expand fleet capacity while maintaining strict budget discipline. With minimal depreciation already absorbed by the first owner, you gain access to near-new performance metrics without the financial burden of showroom pricing.
- Year: 2021
- Manufacturer: XCMG
- Model: 20L5
- Location: Hunan Loudi, China
Smart operators recognize that maximizing ROI means investing in quality pre-owned equipment. Contact Fair Trade Machinery today to discuss specifications, shipping logistics, and competitive financing options for this high-value unit.
| Specifications | Value |
|---|---|
| No. | 1022373 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
