Product Description
Engineered for demanding material handling operations, this 2014 XCMG LW300KN wheel loader combines proven hydraulic architecture with robust mechanical design. Powered by a YC6J125Z-T22 engine delivering 92kW at 2000 rpm, the unit provides reliable torque across a dual-speed transmission system—15/20 km/h in first gear, reaching 40 km/h maximum in second gear for efficient site-to-site repositioning.
Built on a 2900mm wheelbase with 1850mm wheel base configuration, the machine achieves a 38° transaxle swing angle for precise material placement. The hydraulic system executes lift cycles in 5.6 seconds with 9.8-second ternary operations, maximizing productivity in loading applications. With a 3000kg rated load capacity and 28° maximum climbing ability, this loader handles challenging terrain while maintaining operational stability.
Key Technical Specifications:
- Overall dimensions: 7250mm (L) × 2482mm (W) × 3390mm (H)
- 17.5-25-12PR industrial-grade tire specification
- YC6J125Z-T22 turbocharged diesel engine
- Dual-range transmission with 40 km/h top speed
- Currently located in Baoding, Hebei Province
| Specifications | Value |
|---|---|
| No. | 1011408 |
| Engine type | YC6J125Z-T22 |
| Rated power (kw/rpm) | 92/2000 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | |
| Machine operating weight (kg) | |
| Max - Unloading height (mm) | |
| Unloading distance (mm) | |
| Maximum tractive force (kN) | |
| Maximum climbing ability (°) | 28 |
| Wheelbase (mm) | 2900 |
| Wheel base (mm) | 1850 |
| Machine length (mm) | 7250 |
| Machine width (mm) | 2482 |
| Machine height (mm) | 3390 |
| Transaxle swing Angle (°) | 38 |
| Tyre specification | 17.5-25-12PR |
| Minimum turning radius of outer wheel center line | |
| Lift (s) | 5.6 |
| Ternary sum (s) | 9.8 |
| Speed 1 gear (km/h) | 15/20 |
| Speed 2 (km/h) | 40 |
| Maximum speed (km/h) | 40 |
