Product Description
This 2019 XCMG LW500D wheel loader presents an excellent opportunity for operators seeking proven performance in material handling applications. With just over 3,000 operational hours, this machine remains in its early service life, offering substantial residual value and years of productive capacity ahead.
The LW500D is engineered for demanding loading cycles in quarries, construction sites, and bulk material operations. Its robust drivetrain and hydraulic systems deliver consistent bucket breakout force and efficient fuel consumption across extended shifts.
- Operating hours: 3,000+
- Current location: Jiangxi Province, China
- Suitable for aggregate handling, stockpile management, and truck loading
- Well-maintained unit from a premium Chinese manufacturer
Available for immediate inspection and purchase. Contact us for detailed service records, current condition assessment, and export documentation assistance.
| Specifications | Value |
|---|---|
| No. | 1168150 |
| Engine type | WD10G220E23 |
| Rated power (kw/rpm) | 162/2000 |
| Bucket capacity (m³) | 2.8 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 165 |
| Machine operating weight (kg) | 16900 |
| Max - Unloading height (mm) | 3150~3560 |
| Unloading distance (mm) | 1160 |
| Maximum tractive force (kN) | |
| Maximum climbing ability (°) | 28 |
| Wheelbase (mm) | 2960 |
| Wheel base (mm) | 2250 |
| Machine length (mm) | 7800 |
| Machine width (mm) | 3016 |
| Machine height (mm) | 3360 |
| Transaxle swing Angle (°) | 35 |
| Tyre specification | 23.5-25 |
| Minimum turning radius of outer wheel center line | |
| Lift (s) | |
| Ternary sum (s) | |
| Speed 1 gear (km/h) | |
| Speed 2 (km/h) | |
| Maximum speed (km/h) | 38 |
