Product Description
This 2019 XCMG LW60G wheel loader offers reliable performance for material handling and loading operations. Manufactured by one of China's leading construction equipment producers, this machine combines proven engineering with practical functionality suited for quarries, construction sites, and industrial applications.
- Year of Manufacture: 2019
- Model: XCMG LW60G
- Equipment Type: Wheel Loader
- Current Location: Hunan Province, China
- Condition: Used, operational
The LW60G is designed for medium-duty loading tasks with straightforward controls and serviceability. This unit is available for immediate inspection and suitable for buyers seeking cost-effective loader capacity. All equipment sold as-is with standard commercial terms applicable to used heavy machinery transactions.
| Specifications | Value |
|---|---|
| No. | 1168850 |
| Engine type | |
| Rated power (kw/rpm) | 178/2200 |
| Working form | |
| Exhaust volume (L) | 8.29 |
| Bucket capacity (m³) | 3.3 |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Digging force (lifting force) (kN) | 198 |
| Machine operating weight (kg) | 20500 |
| Unloading height - Unloading Angle 45°(mm) | 3100 |
| Unloading distance - Unloading Angle 45°(mm) | 1250 |
| Maximum tractive force (kN) | 165 |
| Maximum climbing ability (°) | 28 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 180 |
| Engine Oil (L) | 27.6 |
| Wheelbase (mm) | 3400 |
| Wheel base (mm) | 2200 |
| Minimum ground clearance (mm) | 450 |
| Machine length (mm) | 8593 |
| Machine width (mm) | 2833 |
| Machine height (mm) | 3534 |
| Minimum turning radius of outer wheel center line | 6482 |
| Turning radius - Outside of bucket (mm) | 7525 |
| Rated working pressure (bars) | 16 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 6 |
| Speed 2 (km/h) | 11 |
| Speed 3 (km/h) | 22 |
| Speed 4 (km/h) | 35 |
