Product Description
Backed by China's largest construction machinery manufacturer, this 2019 XCMG XCT20L5 represents a calculated investment in proven engineering. XCMG's extensive dealer network ensures parts availability remains consistent throughout the equipment's operational life, minimizing downtime and protecting your bottom line. Currently located in Lianyungang, Jiangsu, this 20-ton crane benefits from the brand's strong residual value retention in secondary markets—a direct result of XCMG's reputation for durability and widespread fleet adoption across Asia and beyond.
- Comprehensive parts supply chain through authorized XCMG service centers
- Strong resale demand due to brand recognition and fleet standardization
- Factory-backed technical support and documentation readily accessible
- Proven track record in Chinese infrastructure projects since 2019
For operators prioritizing long-term asset value and serviceability, XCMG equipment delivers measurable advantages. This XCT20L5 offers the reliability of an established platform with the practical benefits of sourcing from the world's third-largest crane manufacturer.
| Specifications | Value |
|---|---|
| No. | 1034050 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
