Product Description
Available for immediate sale: a used XCMG XE135B hydraulic excavator, purchased in 2018 and currently located in Guangxi, China. This is a 13-tonne-class tracked machine in a configuration widely used for earthmoving, trenching, utility installation and general civil construction work.
The XE135B sits in XCMG's mainstream mid-size excavator range, with parts and service support that are straightforward to source in the Chinese market — an advantage for contractors planning long-term deployment across multiple project sites.
Listing details as provided by the seller: year 2018, brand XCMG, model XE135B, location Guangxi, China, reference price RMB 135,000.
Operating hours, undercarriage wear, attachment options and maintenance history are not specified in the source information. These can be confirmed with the seller before purchase, and inspection in Guangxi can be arranged on request.
Buyers looking for a serviceable production machine rather than a low-hour premium unit may find this a practical entry point into the 13-tonne class. Enquiries are welcome from both domestic and export buyers.
| Specifications | Value |
|---|---|
| No. | 1156949 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
