Product Description

This 2018 XCMG XE135B hydraulic excavator offers reliable performance for contractors and construction operations. Manufactured by one of China's leading heavy equipment producers, this 13.5-ton class machine combines proven durability with operational efficiency. Currently located in Sichuan, China, the unit is available for immediate deployment or export.

The XE135B is designed for versatility across earthmoving, foundation work, and general excavation applications. Its mid-size configuration provides an optimal balance between digging power and maneuverability on confined job sites.

  • Year: 2018
  • Model: XCMG XE135B
  • Weight Class: 13.5 tons
  • Location: Sichuan, China
  • Condition: Used, operational

Ideal for buyers seeking cost-effective excavation capacity with established XCMG engineering and parts support throughout Asia and international markets.

SpecificationsValue
No.1163242
Tonnage (tons)13
Working weight (kg)13800
Bucket capacity (m³)0.4-0.52
Boom length (mm)4600
Rod length (mm)2510
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeISUZU BB-4BG1TRP
Rated power (kw/rpm)69.6/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)4.329
Working formturbocharging
Ground specific pressure (Kpa)42
Rotation speed (rpm)12.3
Climbing ability (%)35 °
Bucket digging force (kN)85
Rod digging force (kN)65
Travel speed (km/h)5.16/3.03
Main overflow set pressure (Mpa)31.4/34.3
Maximum flow of main pump (l/min)2*123
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Hydraulic crushing pipeline is standardno
Main pump typeTwo plunger pumps
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)250
Hydraulic Tank (L)130
Engine Oil changes (L)14
Total transport length (mm)7770
Total transport width (mm)2512
Total transport height (mm)2880
Counterweight ground clearance (mm)964
Minimum ground clearance (mm)478
Minimum turning radius of front working device (mm)2335
Back end turning radius (mm)2294
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2910
Maximum digging radius (mm)8296
Maximum digging depth (mm)5538
Maximum excavation height (mm)8641
Maximum unloading height (mm)6181
Maximum vertical digging depth (mm)4727
