Product Description
Used 2019 XCMG XE135B hydraulic excavator, offered for sale from a working yard in Yunnan, China. The XE135B sits in the 13-tonne class, the backbone of mid-size earthmoving fleets, and is routinely deployed on trenching, site preparation, road works, utility installation and general civil construction.
- Year: 2019
- Brand: XCMG
- Model: XE135B
- Machine type: crawler hydraulic excavator, 13-tonne class
- Location: Yunnan, China
- Asking price: RMB 128,000
- Status: available now, seller motivated to close quickly
The machine is sold as-is, where-is. Buyers are welcome to arrange inspection, on-site or by video, to verify undercarriage wear, hydraulic performance, hour meter reading and attachment condition before committing. Full details and additional photographs are available on request. We can support loading, inland transport and export documentation for overseas purchasers, and can advise on the most practical route out of Yunnan to your destination port. Serious enquiries only; price reflects a fast sale rather than a distressed unit.
| Specifications | Value |
|---|---|
| No. | 1156253 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
