2022 XCMG XE135B

1/7
Buy XCMG XE135B Used Excavator / 1
Buy XCMG XE135B Used Excavator / 2
Buy XCMG XE135B Used Excavator / 3
Buy XCMG XE135B Used Excavator / 4
Buy XCMG XE135B Used Excavator / 5
Buy XCMG XE135B Used Excavator / 6
Buy XCMG XE135B Used Excavator / 7

Product Description

This 2022 XCMG XE135B excavator represents a solid opportunity for operators seeking reliable mid-size equipment. As a first-owner machine with verified operational performance, this 13.5-ton class excavator demonstrates XCMG's engineering quality in a compact, versatile platform suitable for construction, demolition, and earthmoving applications.

  • Year: 2022
  • Model: XCMG XE135B
  • Class: 13.5-ton hydraulic excavator
  • Condition: Used, single owner, performance verified
  • Location: Zhejiang Province, China

The XE135B offers dependable hydraulic performance and fuel efficiency appropriate for mid-range excavation work. Currently located in Zhejiang, this machine is available for inspection. Suitable for contractors looking to expand fleet capacity or replace aging equipment with a recent-year model backed by XCMG's established service network throughout China and international markets.

SpecificationsValue
No.1167397
Tonnage (tons)13
Working weight (kg)13800
Bucket capacity (m³)0.4-0.52
Boom length (mm)4600
Rod length (mm)2510
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeISUZU BB-4BG1TRP
Rated power (kw/rpm)69.6/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)4.329
Working formturbocharging
Ground specific pressure (Kpa)42
Rotation speed (rpm)12.3
Climbing ability (%)35 °
Bucket digging force (kN)85
Rod digging force (kN)65
Travel speed (km/h)5.16/3.03
Main overflow set pressure (Mpa)31.4/34.3
Maximum flow of main pump (l/min)2*123
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Hydraulic crushing pipeline is standardno
Main pump typeTwo plunger pumps
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)250
Hydraulic Tank (L)130
Engine Oil changes (L)14
Total transport length (mm)7770
Total transport width (mm)2512
Total transport height (mm)2880
Counterweight ground clearance (mm)964
Minimum ground clearance (mm)478
Minimum turning radius of front working device (mm)2335
Back end turning radius (mm)2294
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2910
Maximum digging radius (mm)8296
Maximum digging depth (mm)5538
Maximum excavation height (mm)8641
Maximum unloading height (mm)6181
Maximum vertical digging depth (mm)4727
see more

Overview

No.1167397

Brand Name:

XCMG

Model Number:

XE135B

Year:

2022

Location:

Zhejiang China

Pub Date:
