Product Description
Available now in Sichuan, China: a 2024 XCMG XE135B hydraulic excavator offered from a single local owner with just over 2,000 operating hours. The machine is a first-hand unit, retained in original condition with no multiple-owner history, and represents low-hour inventory in the 13-tonne class. It has been kept on local work and is presented as a clean, ready-to-operate example rather than a rebuilt or refurbished unit.
- Year of manufacture: 2024
- Operating hours: approximately 2,000+
- Ownership: local first-hand unit, one owner
- Location: Sichuan, China — available for on-site inspection
- Condition: well maintained, original paint, work-ready
Suited to earthmoving, trenching, utility work, and general civil construction duty. The machine is on site in Sichuan and can be inspected by appointment or reviewed via video walkaround for overseas buyers. Documentation and hour meter verification available on request for serious enquiries.
Contact FairTradeMachinery for pricing, detailed photos, and shipping arrangements from China.
| Specifications | Value |
|---|---|
| No. | 1157656 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
