Product Description
Available now from Hunan, China — skip the factory lead times and get this 2019 XCMG XE135D 13-ton crawler excavator working on your site faster. Built for medium-duty earthmoving, demolition, and civil construction, this machine ships direct from its current location, cutting weeks off your procurement timeline. Fast deployment means less downtime and more production from day one.
Powered by a Cummins QSF3.8 four-cylinder, water-cooled, turbocharged engine producing 86 kW at 2,200 RPM with a peak torque of 470 N·m, this unit delivers reliable performance without sacrificing fuel efficiency. The dual main pumps flow 125.4 L/min each, supporting responsive hydraulic control across all working circuits.
- Working Weight: 13,200 kg | Ground Pressure: 40.4 kPa
- Bucket Capacity: 0.32–0.61 m³ (standard 0.52 m³ backhoe)
- Max Digging Depth: 5,546 mm | Max Digging Radius: 8,304 mm
- Bucket Digging Force: 99.1 kN | Rod Digging Force: 68 kN
- Max Tractive Force: 134 kN | Travel Speed: 5.2/2.9 km/h
- Fuel Tank: 260 L | Hydraulic Tank: 105 L
- Transport Dimensions: 7,795 mm (L) × 2,525 mm (W) × 2,880 mm (H)
- Location: Hunan, China — ready for immediate export
| Specifications | Value |
|---|---|
| No. | 1144189 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13200 |
| Bucket capacity (m³) | 0.32-0.61 (0.52) |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSF3.8 |
| Rated power (kw/rpm) | 86/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 470/1300 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.8 |
| Working form | Efi, Direct injection, 4-stroke, turbocharged |
| Ground specific pressure (Kpa) | 40.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 99.1 |
| Rod digging force (kN) | 68 |
| Maximum tractive force (kN) | 134 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 125.4*2 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Working Hydraulic Circuit (Mpa) | 31.4/34.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 105 |
| Engine Oil changes (L) | 11 |
| Total transport length (mm) | 7795 |
| Total transport width (mm) | 2525 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 931 |
| Minimum ground clearance (mm) | 466 |
| Minimum turning radius of front working device (mm) | 2445 |
| Back end turning radius (mm) | 2325 |
| Total track length (mm) | 3648 |
| Track gauge (mm) | 1990 |
| Total track width (mm) | 500 |
| Maximum digging radius (mm) | 8304 |
| Maximum digging depth (mm) | 5546 |
| Maximum excavation height (mm) | 8638 |
| Maximum unloading height (mm) | 6174 |
| Maximum vertical digging depth (mm) | 4698 |
| Maximum effective digging depth (mm) | 5335 |
