Product Description
With a powerful QSB7 engine delivering 135 kW at 2050 rpm, the XCMG XE205DA excavator is designed for demanding tasks. Located in 浙江杭州, this 20-ton machine is site-ready for immediate deployment. Equipped with a 1.0-1.2 m³ backhoe bucket and a 5680 mm boom, it excels in digging, grading, and demolition. The robust 21500 kg working weight ensures stability, while the 47.5 Kpa ground specific pressure minimizes soil impact. Achieve maximum digging depths of 6660 mm and a digging force of 157 kN, making short work of tough materials. Travel speeds of 5.7/3.1 km/h and a 35% climbing ability enhance mobility on rugged terrain. A 400 L fuel tank and 220 L hydraulic tank support extended operations without refueling. Ready to tackle any job, the XE205DA is a reliable addition to your fleet.
- Engine: QSB7, 135 kW, water-cooled, 6-cylinder
- Bucket capacity: 1.0-1.2 m³
- Boom length: 5680 mm
- Maximum digging depth: 6660 mm
- Fuel tank: 400 L
- Hydraulic tank: 220 L
| Specifications | Value |
|---|---|
| No. | 1023335 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
