Product Description
This 2015 XCMG XE215CA hydraulic excavator offers reliable performance for mid-range earthmoving operations. As part of XCMG's proven CA series, this 21-ton class machine combines operational efficiency with straightforward maintenance requirements. Currently located in Guizhou, China, this unit represents a cost-effective solution for contractors and equipment fleet managers seeking dependable excavation capacity.
The XE215CA features XCMG's robust hydraulic system designed for demanding construction and mining applications. With over a decade of field-proven service in challenging terrain, this excavator demonstrates the durability expected from China's leading heavy equipment manufacturer.
- Operating weight: approximately 21,500 kg
- Engine: diesel power plant suited for continuous duty cycles
- Standard bucket configuration for general excavation work
- Hydraulic system engineered for responsive control
- Available for inspection in Guizhou province
Suitable for infrastructure development, material handling, and general construction applications requiring medium-class excavation capabilities.
| Specifications | Value |
|---|---|
| No. | 1080888 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu CC-6BG1TRP |
| Rated power (kw/rpm) | 128.5/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 637/1800 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.494 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cooling |
| Ground specific pressure (Kpa) | 45.5 |
| Rotation speed (rpm) | 13.3 |
| Climbing ability (%) | 35 or less |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.5/3.3 |
| Maximum flow of main pump (l/min) | 2 x 209 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Main pump type | 2 plunger pumps |
| Fuel Tank (L) | 360 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 9565 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2790 |
| Onboard width (mm) | 2710 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4270 |
| Maximum digging radius (mm) | 9925 |
| Maximum digging depth (mm) | 6655 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6800 |
| Maximum vertical digging depth (mm) | 5695 |
