2019 XCMG XE225DK

1/5
Buy XCMG XE225DK Used Excavator / 1
Buy XCMG XE225DK Used Excavator / 2
Buy XCMG XE225DK Used Excavator / 3
Buy XCMG XE225DK Used Excavator / 4
Buy XCMG XE225DK Used Excavator / 5

Product Description

This 2019 XCMG XE225DK excavator offers reliable performance for medium to heavy-duty applications. The XE225DK is part of XCMG's proven excavator lineup, designed for durability and operational efficiency in demanding work environments.

Currently located in Fujian, China, this machine represents solid value for contractors and equipment operators seeking dependable used machinery. The 2019 model year provides a balance of modern features and proven technology at a competitive price point.

Key features include:

  • XCMG XE225DK model designation
  • 2019 manufacture year
  • Suitable for excavation, grading, and material handling
  • Available for inspection in Fujian, China

Contact us for detailed specifications, current condition assessment, and export documentation assistance.

SpecificationsValue
No.1173004
Tonnage (tons)22
Working weight (kg)22100
Bucket capacity (m³)1.0-1.2 (1.14)
Boom length (mm)5680
Rod length (mm)2910
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4HK1
Rated power (kw/rpm)140/2000
Cooling modewater-cooling
Maximum torque (N.m)676/1800
Number of cylinders (PCS)4
Displacement (L)5.3
Working formEfi, 4-stroke, turbocharged, air-to-air cold
Ground specific pressure (Kpa)47.2
Rotation speed (rpm)11.8
Climbing ability (%)35
Bucket digging force (kN)149
Rod digging force (kN)111
Maximum tractive force (kN)184
Travel speed (km/h)5.3/3.0
Fuel Tank (L)400
Engine Oil changes (L)19.5
Hydraulic System (L)220
Total transport length (mm)9625
Total transport width (mm)2990
Total transport height (mm)3100
Counterweight ground clearance (mm)1050
Minimum ground clearance (mm)486
Minimum turning radius of front working device (mm)3530
Back end turning radius (mm)2890
Total track length (mm)4255
Track gauge (mm)2390
Total track width (mm)600
Maximum digging radius (mm)9940
Maximum digging depth (mm)6680
Maximum excavation height (mm)9620
Maximum unloading height (mm)6780
Maximum vertical digging depth (mm)5715
see more

Overview

No.1173004

Brand Name:

XCMG

Model Number:

XE225DK

Year:

2019

Location:

Fujian China

Pub Date:
