Product Description
Engineered for precision and durability, the XCMG XE245DK is a 24-ton hydraulic excavator built around a Cummins QSB7 six-cylinder engine delivering 150 kW at 2,050 rpm. With 6.7L displacement and an EFI, 4-stroke turbocharged configuration featuring air-to-air intercooling, this machine delivers consistent power output across demanding excavation cycles.
At the core of its hydraulic performance, bucket digging force reaches 185 kN with rod digging force rated at 129 kN — figures that reflect serious engineering for heavy-duty earthmoving. A 400L fuel tank and 220L hydraulic tank support extended operations without interruption.
- Working weight: 25,500 kg | Ground pressure: 56.7 kPa
- Bucket capacity: 0.9–1.4 m³ | Boom length: 6,000 mm
- Maximum digging depth: 6,972 mm | Maximum digging radius: 10,240 mm
- Maximum unloading height: 7,123 mm
- Maximum tractive force: 199 kN | Travel speed: 5.3 / 3.6 km/h
- Climbing ability: 35% | Swing speed: 11.2 rpm
- Transport dimensions: 10,170 × 3,190 × 3,130 mm
- Currently available in Hunan, China — 2020 build
| Specifications | Value |
|---|---|
| No. | 1144191 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 0.9-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 56.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 199 |
| Travel speed (km/h) | 5.3/3.6 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1062 |
| Minimum ground clearance (mm) | 1062 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6972 |
| Maximum excavation height (mm) | 10048 |
| Maximum unloading height (mm) | 7123 |
| Maximum vertical digging depth (mm) | 5567 |
