Product Description
This 2022 XCMG XE245DK excavator is located in Chongqing, China, and represents a well-maintained earthmoving machine from one of China's leading heavy equipment manufacturers. The unit has been primarily used for excavation and earthwork applications, demonstrating XCMG's proven hydraulic technology and operator-focused cab design.
Key features include:
- XCMG's reliable hydraulic system for consistent digging performance
- Purpose-built for earthmoving and excavation operations
- Well-maintained internal components
- Available for purchase or lease with financing options
The XE245DK is suited for contractors and operators seeking a mid-sized excavator with proven durability. This unit offers an opportunity to acquire recent-year XCMG equipment at competitive used pricing. Inspection and shipping arrangements can be coordinated from the Chongqing location.
| Specifications | Value |
|---|---|
| No. | 1170749 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 0.9-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 56.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 199 |
| Travel speed (km/h) | 5.3/3.6 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1062 |
| Minimum ground clearance (mm) | 1062 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6972 |
| Maximum excavation height (mm) | 10048 |
| Maximum unloading height (mm) | 7123 |
| Maximum vertical digging depth (mm) | 5567 |
