Product Description
This 2022 XCMG XE245DK excavator is now available from Chongqing, China. Originally acquired as a debt recovery asset, this machine has been dedicated to pure earthmoving applications throughout its service life. The XE245DK represents XCMG's mid-range excavator series, designed for demanding construction and excavation projects.
Key highlights include:
- Recent manufacture year ensuring modern engineering standards
- Pure earthwork service history with competitive pricing
- Suitable for contractors seeking reliable excavation capacity
- Available for purchase or rental arrangements
- Installment financing options supported
The XCMG XE245DK is engineered for productivity in earthmoving operations, offering dependable performance for construction sites, mining support, and infrastructure development. Contact us for detailed inspection reports, current operating hours, and flexible acquisition terms tailored to your project requirements.
| Specifications | Value |
|---|---|
| No. | 1171198 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 0.9-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 56.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 199 |
| Travel speed (km/h) | 5.3/3.6 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1062 |
| Minimum ground clearance (mm) | 1062 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6972 |
| Maximum excavation height (mm) | 10048 |
| Maximum unloading height (mm) | 7123 |
| Maximum vertical digging depth (mm) | 5567 |
