Product Description
This 2018 XCMG XE270DK hydraulic excavator offers proven performance for earthmoving and construction applications. The 27-ton class machine features XCMG's reliable powertrain and robust undercarriage design, built to handle demanding jobsite conditions. Currently located in Sichuan, China, this unit is available without bucket attachment, allowing buyers to configure tooling to their specific requirements.
- Year: 2018
- Model: XCMG XE270DK
- Operating weight class: 27 tons
- Configuration: Excavator without bucket
- Location: Sichuan, China
The XE270DK series is known for fuel efficiency and straightforward maintenance access. This unit represents a cost-effective solution for contractors seeking reliable hydraulic excavator capacity. Suitable for general excavation, trenching, material handling, and site development work. Inspection welcomed prior to purchase.
| Specifications | Value |
|---|---|
| No. | 1140699 |
| Tonnage (tons) | 27 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.1-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Maximum torque (N.m) | 825/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 52.1 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 220 |
| Travel speed (km/h) | 6.1/3.8 |
| Maximum flow of main pump (l/min) | 2*259 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1090 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6925 |
| Maximum excavation height (mm) | 10095 |
| Maximum unloading height (mm) | 7170 |
| Maximum vertical digging depth (mm) | 5620 |
