Product Description
Expand your operational capacity with this 2021 XCMG XE335C hydraulic excavator, a 33-ton workhorse engineered for contractors managing multiple jobsites simultaneously. Powered by a 184kW ISUZU turbocharged engine and twin plunger pumps delivering 2×280 L/min flow, this machine integrates seamlessly into existing fleets requiring consistent performance across demolition, earthmoving, and site preparation projects.
Built in Xuzhou with proven Chinese manufacturing standards, this excavator delivers reliable backup support during peak seasonal demand or equipment rotation schedules. Key operational specifications include:
- 10,720mm maximum digging reach with 6,912mm depth capability
- 263kN bucket digging force through a 1.4-1.6m³ capacity attachment
- 630L fuel tank supporting extended shift operations
- 9.7 RPM rotation speed and 35° climbing ability for varied terrain
- 3,183mm track ground length ensuring 66kPa ground pressure distribution
Currently located in Shaanxi Province, this XE335C arrives ready for immediate deployment, minimizing downtime between acquisition and productivity. Standardized hydraulic circuits and water-cooled systems simplify maintenance inte
| Specifications | Value |
|---|---|
| No. | 1026210 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 33800 |
| Bucket capacity (m³) | 1.4-1.6 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 2670 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | The ISUZU Isuzu |
| Rated power (kw/rpm) | 184/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Turbocharged/air-to-air cooling |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 9.7 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 263 |
| Rod digging force (kN) | 225 |
| Travel speed (km/h) | 5.5/3.3 |
| Main overflow set pressure (Mpa) | 34.3/37 |
| Maximum flow of main pump (l/min) | 2*280 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot pump flow (L/min) | 3.9 |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 320 |
| Engine Oil changes (L) | 28 |
| Total transport length (mm) | 11226 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3330 |
| Counterweight ground clearance (mm) | 1170 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 4424 |
| Back end turning radius (mm) | 3450 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3183 |
| Maximum digging radius (mm) | 10720 |
| Maximum digging depth (mm) | 6912 |
| Maximum excavation height (mm) | 10360 |
| Maximum unloading height (mm) | 7134 |
| Maximum vertical digging depth (mm) | 6480 |
