2021 XCMG XE380DK

1/8
Buy XCMG XE380DK Used Excavator / 1
Buy XCMG XE380DK Used Excavator / 2
Buy XCMG XE380DK Used Excavator / 3
Buy XCMG XE380DK Used Excavator / 4
Buy XCMG XE380DK Used Excavator / 5
Buy XCMG XE380DK Used Excavator / 6
Buy XCMG XE380DK Used Excavator / 7
Buy XCMG XE380DK Used Excavator / 8

Product Description

This 2021 XCMG XE380DK hydraulic excavator offers reliable performance for demanding earthmoving and construction applications. Manufactured by XCMG, a leading Chinese heavy equipment producer, this 38-ton class machine features robust construction and proven hydraulic systems suitable for infrastructure development, mining support, and large-scale excavation projects.

  • Year of Manufacture: 2021
  • Model: XE380DK
  • Operating Weight Class: 38 tons
  • Current Location: Shandong Province, China
  • Condition: Used, operational
  • Availability: Immediate inspection and detailed documentation available upon request

This unit is competitively priced for the regional market. Prospective buyers are welcome to arrange on-site inspection, request additional photographs, and review operational video footage. Suitable for contractors seeking cost-effective capacity expansion in Asian markets.

SpecificationsValue
No.1174225
Tonnage (tons)38
Working weight (kg)38200
Bucket capacity (m³)1.9-2.3
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeQSL9
Rated power (kw/rpm)214/2100
Cooling modewater-cooling
Number of cylinders (PCS)6
Displacement (L)8.9
Working formEfi, 4-stroke, turbocharged, air-to-air cold
Ground specific pressure (Kpa)69
Rotation speed (rpm)9.6
Climbing ability (%)35
Bucket digging force (kN)292
Rod digging force (kN)209
Maximum tractive force (kN)285
Travel speed (km/h)5.6/3.3
Fuel Tank (L)660
Hydraulic Tank (L)350
Engine Oil changes (L)30
Total transport length (mm)11437
Total transport width (mm)3225
Total transport height (mm)3715
Full cab height (mm)3050
Counterweight ground clearance (mm)1227
Minimum ground clearance (mm)505
Minimum turning radius of front working device (mm)4560
Back end turning radius (mm)3700
Total track length (mm)5035
Track gauge (mm)2590
Total track width (mm)600
Maximum digging radius (mm)10968
Maximum digging depth (mm)7147
Maximum excavation height (mm)10508
Maximum unloading height (mm)7300
Maximum vertical digging depth (mm)6542
