Product Description

This 2020 XCMG XE490DK hydraulic excavator represents a compelling value proposition for contractors seeking reliable heavy-duty performance. With approximately 4 years of operational history, this 49-ton class machine delivers robust digging capabilities suitable for large-scale earthmoving, demolition, and infrastructure projects.

Currently located in Zhejiang, China, this unit offers an attractive entry point into XCMG's proven excavator lineup. The XE490DK series is engineered for demanding applications with strong breakout force and efficient fuel consumption characteristics.

  • Year of Manufacture: 2020
  • Model: XCMG XE490DK
  • Operating Weight Class: 49 tons
  • Location: Zhejiang Province, China
  • Suitable for: Mining, quarrying, heavy construction

This machine is available for immediate inspection and delivery. Contact our sales team for detailed specifications, current condition assessment, and competitive pricing information.

SpecificationsValue
No.1149219
Tonnage (tons)49
Working weight (kg)48100-49500
Bucket capacity (m³)2.3-3.1
Boom length (mm)6670
Rod length (mm)2900
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeQSM11
Rated power (kw/rpm)280/2000
Ground specific pressure (Kpa)85
Rotation speed (rpm)9.2
Climbing ability (%)70
Bucket digging force (kN)301
Rod digging force (kN)248
Maximum tractive force (kN)338
Travel speed (km/h)5.4/3.2
Maximum flow of main pump (l/min)2*360
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)31
Main pump typeTwo plunger pumps
Fuel Tank (L)725
Hydraulic Tank (L)430
Engine Oil changes (L)38
Total transport length (mm)11808
Total transport width (mm)3582
Total transport height (mm)3890
Counterweight ground clearance (mm)1324
Minimum ground clearance (mm)519
Minimum turning radius of front working device (mm)4580
Back end turning radius (mm)3800
Total track length (mm)5353
Track gauge (mm)2750
Track plate width (mm)600
Maximum digging radius (mm)10855
Maximum digging depth (mm)7000
Maximum excavation height (mm)9855
Maximum unloading height (mm)6890
Maximum vertical digging depth (mm)4500
Maximum effective digging depth (mm)6900
see more

Overview

No.1149219

Brand Name:

XCMG

Model Number:

XE490DK

Year:

2020

Location:

Zhejiang China

Pub Date:
