Product Description
2021 XCMG XE490DK excavator available from Chongqing, China. This machine retains its original factory paint and finish, indicating careful operation and minimal cosmetic wear throughout its service life.
The XE490DK represents XCMG's heavy-duty excavator platform designed for demanding earthmoving, mining, and large-scale construction applications. With approximately three years of operational history, this unit offers proven reliability at a competitive price point.
- Year: 2021
- Manufacturer: XCMG
- Model: XE490DK
- Location: Chongqing, China
- Condition: Original factory paint
- Availability: Purchase or lease options
- Financing: Installment payment plans available
Suitable for contractors seeking heavy excavation capacity with flexible acquisition terms. Contact us for detailed specifications, inspection arrangements, and financing options tailored to your operational requirements.
| Specifications | Value |
|---|---|
| No. | 1143992 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 48100-49500 |
| Bucket capacity (m³) | 2.3-3.1 |
| Boom length (mm) | 6670 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSM11 |
| Rated power (kw/rpm) | 280/2000 |
| Ground specific pressure (Kpa) | 85 |
| Rotation speed (rpm) | 9.2 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 301 |
| Rod digging force (kN) | 248 |
| Maximum tractive force (kN) | 338 |
| Travel speed (km/h) | 5.4/3.2 |
| Maximum flow of main pump (l/min) | 2*360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 31 |
| Main pump type | Two plunger pumps |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 38 |
| Total transport length (mm) | 11808 |
| Total transport width (mm) | 3582 |
| Total transport height (mm) | 3890 |
| Counterweight ground clearance (mm) | 1324 |
| Minimum ground clearance (mm) | 519 |
| Minimum turning radius of front working device (mm) | 4580 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5353 |
| Track gauge (mm) | 2750 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 10855 |
| Maximum digging depth (mm) | 7000 |
| Maximum excavation height (mm) | 9855 |
| Maximum unloading height (mm) | 6890 |
| Maximum vertical digging depth (mm) | 4500 |
| Maximum effective digging depth (mm) | 6900 |
