HOME>>XCMG>>XCMG XE500C

2020 XCMG XE500C

1/3
Buy XCMG XE500C Used Excavator / 1
Buy XCMG XE500C Used Excavator / 2
Buy XCMG XE500C Used Excavator / 3

Product Description

This 2020 XCMG XE500C hydraulic excavator offers reliable performance for demanding earthmoving operations. Originally deployed in Sichuan, China, this machine represents solid value in the 50-ton class excavator segment. The XE500C is engineered for heavy-duty applications including mining, quarrying, and large-scale construction projects.

XCMG's 500-series excavators are known for their robust build quality and efficient fuel consumption. This unit comes from China's export-grade production line, meeting international standards for hydraulic systems and structural integrity.

  • Year: 2020
  • Model: XCMG XE500C
  • Class: 50-ton hydraulic excavator
  • Current Location: Sichuan, China
  • Condition: Used
  • Suitable for: Mining, quarrying, heavy construction

Available for inspection in Sichuan. Competitive pricing for international buyers seeking proven Chinese manufacturing quality in the heavy equipment sector.

SpecificationsValue
No.1145546
Tonnage (tons)50
Working weight (kg)47300
Bucket capacity (m³)2.1 ~ 2.5
Boom length (mm)7060
Rod length (mm)2900
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeCummins QSM11
Rated power (kw/rpm)250/2100
Maximum torque (N.m/rpm)1674/1400
Number of cylinders (PCS)6
Displacement (L)11
Ground specific pressure (Kpa)85.9
Rotation speed (rpm)9
Climbing ability (%)35
Bucket digging force (kN)284
Rod digging force (kN)236
Maximum tractive force (kN)236
Travel speed (km/h)5.4/3.2
Maximum flow of main pump (l/min)2 x 360
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)28.4
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)725
Hydraulic Tank (L)430
Engine Oil changes (L)38
Total transport length (mm)12032
Total transport width (mm)3724
Total transport height (mm)4165
Counterweight ground clearance (mm)1360
Minimum ground clearance (mm)703(without tooth height)
Back end turning radius (mm)3665
Total track length (mm)5220
Track gauge (mm)2392/2890
Total track width (mm)600
Maximum digging radius (mm)11631
Maximum digging depth (mm)7337
Maximum excavation height (mm)10675
Maximum unloading height (mm)7409
Maximum vertical digging depth (mm)5225
see more

Overview

No.1145546

Brand Name:

XCMG

Model Number:

XE500C

Year:

2020

Location:

Sichuan China

Pub Date
