2014 XCMG XE50C

1/6
Buy XCMG XE50C Used Excavator / 1
Buy XCMG XE50C Used Excavator / 2
Buy XCMG XE50C Used Excavator / 3
Buy XCMG XE50C Used Excavator / 4
Buy XCMG XE50C Used Excavator / 5
Buy XCMG XE50C Used Excavator / 6

Product Description

This 2014 XCMG XE50C compact excavator features an extended arm configuration, offering enhanced reach for versatile digging and loading applications. Originally manufactured by XCMG, a leading Chinese heavy equipment producer, this 5-ton class machine delivers reliable hydraulic performance suitable for construction, landscaping, and utility work.

Key features include:

  • Extended boom assembly for increased working range
  • Robust hydraulic system with strong digging force
  • Compact footprint ideal for confined job sites
  • Economical fuel consumption for operational efficiency
  • Currently located in Guangxi, China

This used excavator represents a cost-effective solution for contractors seeking dependable equipment at competitive pricing. The machine has been maintained in working condition and is available for immediate inspection and delivery arrangements.

SpecificationsValue
No.1170344
Tonnage (tons)5
Working weight (kg)5030
Bucket capacity (m³)0.18
Boom length (mm)2795
Rod length (mm)1600
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4TNV88-SYY
Rated power (kw/rpm)27.6/2200
Maximum torque (N.m/rpm)142/1320
Number of cylinders (PCS)4
Displacement (L)2.19
Ground specific pressure (Kpa)29.5
Rotation speed (rpm)13.5
Climbing ability (%)30 °
Bucket digging force (kN)23.2
Rod digging force (kN)19.3
Maximum tractive force (kN)47.7
Travel speed (km/h)4.2/2.6
Maximum flow of main pump (l/min)1 x 110 + 11
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)16.7
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)65
Hydraulic Tank (L)70
Engine Oil changes (L)7.4
Total transport length (mm)5475
Total transport width (mm)1800
Total transport height (mm)2540
Counterweight ground clearance (mm)675
Minimum ground clearance (mm)381
Back end turning radius (mm)1490
Track gauge (mm)1400
Total track width (mm)400
Maximum digging radius (mm)5810
Maximum digging depth (mm)3555
Maximum excavation height (mm)5412
Maximum unloading height (mm)3788
Maximum vertical digging depth (mm)3115
Bulldozer lift or depth (mm)718/560
Dodging plate width × height (mm)1800/340
see more

Overview

No.1170344

Brand Name:

XCMG

Model Number:

XE50C

Year:

2014

Location:

Guangxi China

Pub Date:
