Product Description
Available now in Sichuan Dazhou, this 2019 XCMG XE50C mini excavator eliminates factory wait times and ships directly to your project site. Powered by a reliable 4TNV88-SYY engine delivering 27.6 kW at 2200 rpm, this 5-ton machine combines compact dimensions with serious digging capability. Skip the lengthy procurement process—this ready-to-deploy unit offers immediate productivity for urban construction, utility work, and confined-space applications across China and international markets.
- Working Weight: 5,030 kg with 0.18 m³ bucket capacity
- Digging Performance: 5,810 mm max reach, 3,555 mm max depth, 23.2 kN bucket force
- Compact Footprint: 1,800 mm transport width, 1,490 mm rear turning radius
- Hydraulic System: 110 L/min main pump flow, 21 MPa travel circuit pressure
- Fast Deployment: Fully inspected, serviced, and ready for immediate shipment from Dazhou
Secure this in-stock XCMG mini excavator today and put equipment on-site weeks ahead of new orders. Contact Fair Trade Machinery for logistics coordination and competitive export pricing.
| Specifications | Value |
|---|---|
| No. | 1039098 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5030 |
| Bucket capacity (m³) | 0.18 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4TNV88-SYY |
| Rated power (kw/rpm) | 27.6/2200 |
| Maximum torque (N.m/rpm) | 142/1320 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 29.5 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Maximum tractive force (kN) | 47.7 |
| Travel speed (km/h) | 4.2/2.6 |
| Maximum flow of main pump (l/min) | 1 x 110 + 11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 16.7 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 7.4 |
| Total transport length (mm) | 5475 |
| Total transport width (mm) | 1800 |
| Total transport height (mm) | 2540 |
| Counterweight ground clearance (mm) | 675 |
| Minimum ground clearance (mm) | 381 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1400 |
| Total track width (mm) | 400 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3555 |
| Maximum excavation height (mm) | 5412 |
| Maximum unloading height (mm) | 3788 |
| Maximum vertical digging depth (mm) | 3115 |
| Bulldozer lift or depth (mm) | 718/560 |
| Dodging plate width × height (mm) | 1800/340 |
