2019 XCMG XE50C

1/9
Buy XCMG XE50C Used Excavator / 1
Buy XCMG XE50C Used Excavator / 2
Buy XCMG XE50C Used Excavator / 3
Buy XCMG XE50C Used Excavator / 4
Buy XCMG XE50C Used Excavator / 5
Buy XCMG XE50C Used Excavator / 6
Buy XCMG XE50C Used Excavator / 7
Buy XCMG XE50C Used Excavator / 8
Buy XCMG XE50C Used Excavator / 9

Product Description

This 2019 XCMG XE50C excavator represents a well-maintained single-owner machine with approximately 3,000 operating hours. Currently located in Yunnan, China, this 5-ton class compact excavator offers reliable performance for construction, landscaping, and utility applications.

The XE50C combines XCMG's proven engineering with practical jobsite versatility. Its compact footprint enables work in space-constrained environments while maintaining productive digging capabilities. Low documented hours indicate limited use and careful operation throughout its service life.

Key attributes include:

  • Single previous owner with verified low hours
  • 5-ton operating weight class for urban and residential projects
  • Compact design suitable for confined work areas
  • XCMG factory build quality and component durability
  • Ready for inspection and immediate deployment

This machine is available for viewing in Yunnan Province. Contact us to arrange technical inspection or discuss export logistics.

SpecificationsValue
No.1156531
Tonnage (tons)5
Working weight (kg)5030
Bucket capacity (m³)0.18
Boom length (mm)2795
Rod length (mm)1600
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4TNV88-SYY
Rated power (kw/rpm)27.6/2200
Maximum torque (N.m/rpm)142/1320
Number of cylinders (PCS)4
Displacement (L)2.19
Ground specific pressure (Kpa)29.5
Rotation speed (rpm)13.5
Climbing ability (%)30 °
Bucket digging force (kN)23.2
Rod digging force (kN)19.3
Maximum tractive force (kN)47.7
Travel speed (km/h)4.2/2.6
Maximum flow of main pump (l/min)1 x 110 + 11
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)16.7
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)65
Hydraulic Tank (L)70
Engine Oil changes (L)7.4
Total transport length (mm)5475
Total transport width (mm)1800
Total transport height (mm)2540
Counterweight ground clearance (mm)675
Minimum ground clearance (mm)381
Back end turning radius (mm)1490
Track gauge (mm)1400
Total track width (mm)400
Maximum digging radius (mm)5810
Maximum digging depth (mm)3555
Maximum excavation height (mm)5412
Maximum unloading height (mm)3788
Maximum vertical digging depth (mm)3115
Bulldozer lift or depth (mm)718/560
Dodging plate width × height (mm)1800/340
see more

Overview

No.1156531

Brand Name:

XCMG

Model Number:

XE50C

Year:

2019

Location:

Yunnan China

Pub Date:
