2020 XCMG XE50C

1/9
Buy XCMG XE50C Used Excavator / 1
Buy XCMG XE50C Used Excavator / 2
Buy XCMG XE50C Used Excavator / 3
Buy XCMG XE50C Used Excavator / 4
Buy XCMG XE50C Used Excavator / 5
Buy XCMG XE50C Used Excavator / 6
Buy XCMG XE50C Used Excavator / 7
Buy XCMG XE50C Used Excavator / 8
Buy XCMG XE50C Used Excavator / 9

Product Description

This 2020 XCMG XE50C compact excavator offers reliable performance for construction, landscaping, and utility applications. Part of XCMG's proven XE series, this 5-ton class machine combines maneuverability with efficient digging capability, making it suitable for confined jobsites and urban projects.

Key features include:

  • 5-ton operating weight for stable performance
  • Compact dimensions for tight access
  • Hydraulic system designed for responsive control
  • Durable undercarriage and swing mechanism
  • Fuel-efficient engine meeting emission standards

Currently located in Sichuan, China, this unit represents a cost-effective solution for contractors seeking dependable excavation equipment. XCMG's widespread service network ensures parts availability and technical support across global markets.

SpecificationsValue
No.1170697
Tonnage (tons)5
Working weight (kg)5030
Bucket capacity (m³)0.18
Boom length (mm)2795
Rod length (mm)1600
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4TNV88-SYY
Rated power (kw/rpm)27.6/2200
Maximum torque (N.m/rpm)142/1320
Number of cylinders (PCS)4
Displacement (L)2.19
Ground specific pressure (Kpa)29.5
Rotation speed (rpm)13.5
Climbing ability (%)30 °
Bucket digging force (kN)23.2
Rod digging force (kN)19.3
Maximum tractive force (kN)47.7
Travel speed (km/h)4.2/2.6
Maximum flow of main pump (l/min)1 x 110 + 11
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)16.7
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)65
Hydraulic Tank (L)70
Engine Oil changes (L)7.4
Total transport length (mm)5475
Total transport width (mm)1800
Total transport height (mm)2540
Counterweight ground clearance (mm)675
Minimum ground clearance (mm)381
Back end turning radius (mm)1490
Track gauge (mm)1400
Total track width (mm)400
Maximum digging radius (mm)5810
Maximum digging depth (mm)3555
Maximum excavation height (mm)5412
Maximum unloading height (mm)3788
Maximum vertical digging depth (mm)3115
Bulldozer lift or depth (mm)718/560
Dodging plate width × height (mm)1800/340
see more

Overview

No.1170697

Brand Name:

XCMG

Model Number:

XE50C

Year:

2020

Location:

Sichuan China

Pub Date:
