Product Description
Ready for dispatch from Hebei, China — this 2022 XCMG XE55DA is available now and needs no factory order. It sits in stock and ships the moment haulage is booked, trading the typical months-long wait for a new build down to days.
Positioned in Hebei, a major equipment logistics hub, the machine moves fast and deploys to your site without production-slot delays. The spec holds up for compact sites and utility work:
- Working weight: 5,750 kg; bucket capacity 0.21 m³
- Kubota V2607 diesel, 35 kW at 2,200 rpm, water-cooled
- Maximum digging depth: 3,830 mm; reach 6,130 mm
- Transport dimensions: 5,860 × 1,920 × 2,585 mm
Get it moving, put it to work, and start breaking ground — not waiting on a production line.
| Specifications | Value |
|---|---|
| No. | 1140729 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5750 |
| Bucket capacity (m³) | 0.21 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607 |
| Rated power (kw/rpm) | 35/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 2.615 |
| Working form | Direct injection, 4 strokes |
| Ground specific pressure (Kpa) | 31 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 48.3 |
| Rod digging force (kN) | 32.5 |
| Maximum tractive force (kN) | 50.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Maximum flow of main pump (l/min) | 150 |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 24 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 77 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 5860 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 700 |
| Minimum ground clearance (mm) | 385 |
| Minimum turning radius of front working device (mm) | 2460 |
| Back end turning radius (mm) | 1670 |
| Track gauge (mm) | 1500 |
| Track plate width (mm) | 400 |
| Center distance of support wheel (mm) | 1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
