Product Description
Engineered for precision work in confined spaces, this 6-ton excavator delivers exceptional operator control and jobsite versatility. Powered by a reliable Yanmar 4TNV94L engine producing 39.8 kW at 2200 rpm, the XE60 combines responsive hydraulics with stable performance across demanding terrain. The Rexroth main pump system provides consistent flow rates (2×60.5+40.3+9.9 l/min) at 22 MPa, ensuring smooth operation of the boom and arm assemblies.
Operator-focused design features include:
- Compact dimensions (5850mm length, 1880mm width) for superior maneuverability in urban environments
- Enhanced visibility with 694mm counterweight clearance and optimized cabin positioning
- Stable platform with 32.1 kPa ground pressure and 1985mm track contact length
- Precise control through dual-speed travel system (4.2/2.2 km/h) and 9.5 rpm rotation speed
- Impressive digging reach of 6130mm with 42.5 kN bucket force
- Standard hydraulic crushing circuit for attachment versatility
Currently located in Baoding, Hebei, this 2021 model represents proven Chinese manufacturing quality with 5960kg working weight and 35° climbing capability for challenging grade work.
| Specifications | Value |
|---|---|
| No. | 1008462 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
