Product Description

Used 2022 XCMG XE60 crawler excavator, offered from Zhejiang, China. This machine entered service in March 2022 and shows 3,800 hours on the working meter — a low-hour example for its year, consistent with light local contracting rather than continuous rental duty.

Key details:

  • Model year: 2022, commissioned March
  • Operating hours: 3,800, meter reading
  • Ownership: one local owner, single-operator history
  • Location: Zhejiang, China — available for on-site inspection
  • Class: 6-ton compact crawler excavator, standard configuration

The XE60 is a common 6-ton class unit on Chinese job sites and is well supported through XCMG's dealer network for parts and service. Single-owner, low-hour machines in this class draw steady interest from contractors and resellers who want a working machine rather than a rebuild project.

Price indication: 60,000+ RMB range. Buyers are welcome to arrange inspection and verify hours and condition before committing.

SpecificationsValue
No.1157391
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.1157391

Brand Name:

XCMG

Model Number:

XE60

Year:

2022

Location:

Zhejiang China

Pub Date:
