Product Description
This 2020 XCMG XE60WA wheeled excavator is now available from Hainan, China. Owner-operated since new, this machine represents a well-maintained example from XCMG's compact excavator range. The XE60WA is designed for versatility in construction, municipal maintenance, and light excavation applications where wheeled mobility offers advantages over tracked alternatives.
- Year of Manufacture: 2020
- Make: XCMG
- Model: XE60WA
- Configuration: Wheeled Excavator
- Current Location: Hainan Province, China
- Ownership: Single owner, operator-maintained
This unit combines road mobility with excavation capability, suitable for urban jobsites and projects requiring frequent relocation. Direct owner sale offers transparency regarding machine history and maintenance records. Interested buyers should contact the seller directly to arrange inspection, discuss operational hours, and verify current condition.
| Specifications | Value |
|---|---|
| No. | 1163770 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
