Product Description
Ready to ship from Hunan, China, this 2023 XCMG XE75C gives you a proven 7-ton mini excavator without the factory wait. Skip the lead times — this unit is available now and can be deployed to your site faster than any new-build order.
Powered by a Kubota V2607 diesel engine producing 43 kW at 2,000 rpm, the XE75C delivers 57 kN of bucket digging force and a 4,020 mm maximum digging depth — reliable output for foundation work, utility trenching, and site prep on tight schedules.
- Working weight: 7,450 kg | Bucket capacity: 0.30 m³
- Rated power: 43 kW / 2,000 rpm | Max torque: 255.8 N.m
- Bucket digging force: 57 kN | Rod digging force: 38 kN
- Max digging radius: 6,260 mm | Max digging depth: 4,020 mm
- Max excavation height: 7,085 mm | Travel speed: 5.4 / 2.9 km/h
- Ground pressure: 33.5 kPa | Fuel tank: 130 L
- Transport dimensions: 6,150 × 2,230 × 2,685 mm
Sourced directly from Hunan and ready for international freight, this XE75C moves on your timeline — not the manufacturer's.
| Specifications | Value |
|---|---|
| No. | 1076570 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
