2024 XCMG XE85C

1/6
Buy XCMG XE85C Used Excavator / 1
Buy XCMG XE85C Used Excavator / 2
Buy XCMG XE85C Used Excavator / 3
Buy XCMG XE85C Used Excavator / 4
Buy XCMG XE85C Used Excavator / 5
Buy XCMG XE85C Used Excavator / 6

Product Description

This 2024 XCMG XE85C excavator is available from Guangxi, China. As a recent-year model from XCMG's versatile midsize range, the XE85C delivers reliable performance for construction, earthmoving, and site development applications. The machine comes equipped with a complete attachment set, enhancing operational flexibility across various job site requirements.

  • Year: 2024
  • Model: XCMG XE85C
  • Location: Guangxi, China
  • Condition: Used
  • Includes: Full attachment set

The XE85C is well-suited for contractors seeking a dependable excavator with low operating hours. XCMG's engineering provides robust hydraulic systems and straightforward maintenance access. This unit represents a practical acquisition for businesses expanding their fleet or replacing aging equipment. Contact us for detailed specifications, current availability, and shipping arrangements to your location.

SpecificationsValue
No.1105266
Tonnage (tons)8
Working weight (kg)7700/8100 (with dozer)
Bucket capacity (m³)0.34
Boom length (mm)3720
Rod length (mm)1622
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4JG1TPC
Rated power (kw/rpm)53.8/2150
Maximum torque (N.m/rpm)255/1800
Number of cylinders (PCS)4
Displacement (L)3.059
Ground specific pressure (Kpa)34.6/36.4 (with dozer)
Rotation speed (rpm)11
Climbing ability (%)35 °
Bucket digging force (kN)51.2
Rod digging force (kN)34.2
Maximum tractive force (kN)34.2
Travel speed (km/h)4.9/2.6
Maximum flow of main pump (l/min)198+21
Traveling Hydraulic Circuit (Mpa)27.4
Rotary Hydraulic Circuit (Mpa)20.6
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)130
Hydraulic Tank (L)115
Engine Oil changes (L)9.7
Total transport length (mm)6144
Total transport width (mm)2332
Total transport height (mm)2712
Counterweight ground clearance (mm)827
Minimum ground clearance (mm)428
Back end turning radius (mm)1805
Track gauge (mm)1870
Total track width (mm)450
Maximum digging radius (mm)6295
Maximum digging depth (mm)4130
Maximum excavation height (mm)7165
Maximum unloading height (mm)5060
Maximum vertical digging depth (mm)3500
Bulldozer lift or depth (mm)409/438
Dodging plate width × height (mm)2320 x 416
see more

Overview

No.1105266

Brand Name:

XCMG

Model Number:

XE85C

Year:

2024

Location:

Guangxi China
