Product Description
Operators demand reliable performance in demanding quarry and mining environments. This 2013 XCMG ZL50G mining-spec wheel loader delivers proven handling characteristics through its hydraulically assisted steering system and load-sensing technology. Built on a reinforced frame architecture, the machine maintains stability during heavy material transfer cycles across uneven terrain.
- Year: 2013
- Brand: XCMG
- Model: ZL50G (Mining Configuration)
- Location: Baoding, Hebei Province
Cabin visibility extends across a wide frontal arc, with strategically positioned glass panels reducing blind spots during bucket positioning. Control responsiveness allows for precise bucket manipulation in confined loading zones. Standard mining reinforcements include enhanced guarding for critical hydraulic components and increased-capacity cooling systems. Currently available for inspection in Baoding, this machine represents practical value for operations requiring dependable material handling capacity without excessive complexity.
| Specifications | Value |
|---|---|
| No. | 1018383 |
| Engine type | |
| Rated power (kw/rpm) | 162/2200 |
| Working form | |
| Exhaust volume (L) | 10.45 |
| Bucket capacity (m³) | 2.5 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 170 |
| Machine operating weight (kg) | 17500 |
| Unloading height - Unloading Angle 45°(mm) | 3090 |
| Unloading distance - Unloading Angle 45°(mm) | 1130 |
| Maximum tractive force (kN) | 150 |
| Maximum climbing ability (°) | 28 |
| Transaxle swing Angle (°) | 12 |
| Steering Angle | 35 |
| Minimum turning radius of outer wheel center line | 6400 |
| Turning radius - Outside of bucket (mm) | 7300 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Machine length (mm) | 8194 |
| Machine width (mm) | 2800 |
| Machine height (mm) | 3460 |
