2012 Caterpillar 329D
Product Description
Strengthen your fleet capacity with this 2012 Caterpillar 329D excavator, currently located in Xuzhou, Jiangsu. Operating at 29 tons with a robust 152kW C7 ACERT engine, this machine delivers consistent performance for contractors managing multiple job sites simultaneously. Its 1.1m³ bucket capacity and 10.6-meter maximum reach handle demanding excavation tasks while maintaining the reliability Caterpillar is known for.
Key specifications include:
- Working weight: 29,240 kg with optimal stability for heavy-duty applications
- Maximum digging depth of 7,170mm and excavation height reaching 9,990mm
- Hydraulic system delivering 235 L/min flow at 35 MPa for responsive operation
- Water-cooled 6-cylinder engine producing reliable power at 2,000 RPM
- Dual travel speeds (3.5/5.3 km/h) for efficient site mobility
Built as a joint venture/import model with Japanese engineering standards, this 329D serves as an ideal backup unit or fleet expansion option. With 520L fuel capacity and proven hydraulic systems, it minimizes downtime while maximizing productivity across concurrent projects. Perfect for contractors requiring dependable secondary equipment without compromising on perf
| Specifications | Value |
|---|---|
| No. | 998235 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Overview
No.998235
Brand Name：
CaterpillarModel Number：
329DYear：
2012
Location：
Jiangsu China
Pub Date：
