Product Description
Engineered with precision by Kobelco's joint venture manufacturing, this 2023 SK130 excavator delivers 13-ton class performance through proven Japanese technology. At its core, the Mitsubishi D04FR engine generates 74 kW at 2000 rpm, providing consistent power delivery across demanding applications. The hydraulic system produces an impressive 90.1 kN bucket digging force, while the 0.52 m³ backhoe bucket handles material with efficiency.
Technical specifications demonstrate superior operational capability:
- Maximum digging reach of 8,340 mm with 5,520 mm depth capacity
- Compact 2,190 mm rear turning radius for confined site maneuverability
- 11.5 rpm rotation speed ensuring productive cycle times
- 70% (35°) climbing ability for challenging terrain navigation
- Dual travel speeds of 3.4/5.6 km/h optimizing transport efficiency
Operating at 12,800 kg working weight, the SK130 maintains stability through its 2,870 mm track gauge and 440 mm ground clearance. The 275-liter fuel tank and 101-liter hydraulic reservoir support extended operation periods. Currently available in Shaoxing, Zhejiang, this machine represents Kobelco's commitment to reliable, specification-driven e
| Specifications | Value |
|---|---|
| No. | 1009364 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
