Product Description
With a working weight of 20,000 kg and a bucket capacity of 0.8 m³, the 2018 Kobelco SK200 is ready for immediate deployment from 福建莆田. Powered by a Mitsubishi 6D34-TLU2D engine, this excavator delivers 110 kW at 2000 rpm, ensuring reliable performance on any job site. Available now, skip the factory lead times and get to work faster. Equipped with a backhoe bucket and double variable displacement axial piston pump, it offers robust digging forces of up to 157 kN in supercharged state. Travel speeds of up to 6.0 km/h in second gear ensure swift movement across your site. With a fuel tank capacity of 340 L and track plate widths of 600 or 800 mm, this machine is designed for efficiency and durability. Fast deployment to your site means you can start your project without delay.
| Specifications | Value |
|---|---|
| No. | 1000361 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
