Product Description
Strengthen your fleet capacity with this reliable 2019 Kobelco SK75 compact excavator, currently available in Heze, Shandong. Operating at 7 tons with a 7,000 kg working weight, this machine delivers consistent performance for contractors managing multiple job sites simultaneously. Powered by an ISUZU AU4LE2X engine producing 41 kW at 2200 rpm, it provides dependable output through water-cooled efficiency and a 2.179L displacement across four cylinders.
Engineered for versatility, this unit features a double variable displacement axial piston pump system with working hydraulic pressure reaching 29.4 Mpa. Operational specifications include a maximum digging depth of 4,160 mm, digging radius of 6,460 mm, and excavation height of 7,390 mm—ideal dimensions for utility work, landscaping, and site preparation tasks.
- Compact footprint: 2,630 mm transport height, 1,290 mm rear turning radius
- Dual travel speeds: 2.8/5.3 km/h for efficient site mobility
- Generous capacities: 120L fuel tank, 72L hydraulic reservoir
- Proven ISUZU power plant with accessible maintenance points
Add operational redundancy and expand project capacity without compromising on quality or performance standar
| Specifications | Value |
|---|---|
| No. | 995001 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
